Android TV / Fire TV (ADB) integration for Gladys Assistant

Control Android TV, Google TV, Shield and Fire TV over network ADB: power, apps, playback, keys.

View on GitHubAll external integrations

Control your Android TV, Google TV, NVIDIA SHIELD, Android boxes and Amazon Fire TV from Gladys, over the local network, with ADB (Android Debug Bridge): power, the application on screen, playback, volume and remote keys, plus scene triggers, scene actions and a dashboard widget.

Developed without the hardware: feedback welcome. The integration is tested against simulated devices built from real outputs, not yet on every model. Tell us on the forum what works on yours.

This integration is not affiliated with Google, Amazon or NVIDIA. Android, Google TV, Fire TV and SHIELD are trademarks of their owners.

Overview​

Each TV or box becomes one device in Gladys, identified by its serial number (not by its IP address). Gladys connects to the device's network debugging port (5555), with a key of its own that you allow once on the screen. Nothing is installed on the device, and no cloud is involved.

What you get:

  • turn the screen on and off, and know whether it is on, in standby or showing the screensaver;
  • the application on screen, by its name (Netflix, YouTube, Prime Video, myCANAL…), and open any installed application from Gladys;
  • the playback state (playing, paused, stopped) of the application on screen;
  • the volume, when the device reports it, and the remote keys (home, back, arrows, OK, playback, volume);
  • scene triggers ("an application comes to the screen", "playback starts, pauses or stops") and scene actions ("open an application", "press a key", "open an address").

Complementary to Android TV Remote​

The Android TV Remote integration uses the protocol of the Google TV remote app (Remote v2). Both can be installed together:

NeedAndroid TV RemoteThis integration (ADB)
Amazon Fire TVnoyes
Open any installed applicationfrom a listyes
Know which application is on screennoyes
Playback state for scenespartialyes
Works without developer optionsyesno
PairingPIN code"Allow debugging?"

Requirements​

  • Gladys Assistant 5.1.0 or later.
  • The device and Gladys on the same local network, the device with a fixed IP address (a DHCP reservation in your router).
  • Developer options and network debugging enabled on the device (below). It is a one-time setup.

Android TV, Google TV, NVIDIA SHIELD​

  1. Settings → Device preferences → About: click Build seven times. "You are now a developer" shows.
  2. Settings → Device preferences → Developer options: enable USB debugging.
  3. On an NVIDIA SHIELD, also enable Network debugging in the same menu: it shows the address to use. On a Chromecast with Google TV and most boxes, USB debugging opens port 5555 on the network.

Some Android 11+ devices only offer "Wireless debugging" (pairing code, random port): that mode is not supported. On such a device, run once adb tcpip 5555 from a computer connected to it (it lasts until the next restart of the device).

Amazon Fire TV​

  1. Settings → My Fire TV → About: click the name of the device seven times.
  2. Settings → My Fire TV → Developer options: enable ADB debugging.

Configuration​

In Gladys: Integrations → Android TV / Fire TV (ADB) → Configuration.

  • Device IP addresses: one address per TV or box, separated by commas, e.g. 192.168.1.50, 192.168.1.51. The port is 5555 unless you add another one (192.168.1.50:5556).
  • Refresh while on: how often a device that is on is read, 5 to 60 seconds (10 by default). A device in standby is read once a minute.
  • Language of the feature names: the names given to the features when you add a device (they do not change afterwards), and the application names sent with the scene events. French by default.

Save, then add the devices from the Discovery tab.

Allowing Gladys on the device​

At the first connection, the screen of the device asks "Allow USB debugging?" with the fingerprint of the key of Gladys. Tick "Always allow from this computer" and accept. Without the tick, the question comes back at every connection.

Gladys asks once by itself, right after you saved the address. If you missed the question (screen off, nobody in front of the TV), turn the TV on and run the Connect the devices action at the bottom of the Configuration screen: the question shows again, and the result tells, for each address, whether Gladys is connected. It also shows the fingerprint of the key, to compare with the one on the screen.

Devices​

Each TV or box is one device, named after its model (you can rename it). Its features:

FeatureTypeWhat it does
PowerTV on/off1 when the screen is on (screensaver included), 0 in standby; switching it wakes or sleeps it
ApplicationSelectionthe application on screen; choosing another one opens it
Playback stateSelection (read)playing, paused, stopped, nothing playing, screensaver, standby
VolumeTV volume (%)the media volume, when the device reports it; setting it changes it
Home, Back, arrows, OKTV buttonsthe navigation keys
Menu, Play, Pause, StopTV buttonsthe menu and playback keys
Next, Previous, Rewind, Fast forwardTV buttonsthe media keys
Volume +, Volume -, MuteTV buttonsthe volume keys (on a box, forwarded to the TV by HDMI-CEC)

The Application list holds the installed applications that open from the home screen, with their names for the common ones (Netflix, YouTube, Prime Video, Disney+, myCANAL, Molotov, france.tv, Arte, Spotify, Deezer, Plex, Kodi, VLC…) and the package name for the others. It is read again every six hours.

Refresh​

Gladys reads each device by itself (it does not rely on the core's polling): every 10 seconds (your setting) while the screen is on, over one connection kept open so that keys respond at once; once a minute in standby, with the connection closed after each read. A read is one shell command on the device (power, activity, media session and audio state), so the load on the device is low. Only the values that change are sent to Gladys, plus a refresh every six hours. There is no account, no cloud and no quota.

Widget​

Dashboard → Edit → add the ADB remote widget, and choose the device. It shows the state (on, screensaver, standby, unreachable), the application on screen, the playback state and the volume, and four buttons of your choice (settings "Button 1" to "Button 4": back, home, play/pause and power by default). Four is the number of buttons Gladys allows per widget: add a second widget for other keys.

Scene triggers​

  • An application comes to the screen: the application in the foreground changed. Filters: the device, a known application, or any package name (e.g. org.videolan.vlc). The scene can use the application name, the package name and the device name.
  • Playback starts, pauses or stops: the media session of the application on screen changed state. Filters: the device and the state. The scene can use the state, the application and the device name.

Both are read at the refresh pace (10 seconds by default), and only while the screen is on. Some applications do not publish their playback state: playback triggers then stay silent for them.

Scene actions​

  • Open an application on the TV: a known application from the list (on a Fire TV, the Fire TV version is chosen), or any package name.
  • Press a remote key: home, back, arrows, OK, menu, play/pause, play, pause, stop, next, previous, rewind, fast forward, volume, mute, power, settings, search; one to twenty presses.
  • Open an address on the TV: an http, https, rtsp or rtmp address, opened by the matching application (a YouTube link opens YouTube), or by the package you name (e.g. org.videolan.vlc for a camera stream).

There is no "run a shell command" action, on purpose: an ADB shell can install, remove or read anything on the device, and a scene can be edited by every Gladys administrator. Home Assistant offers one; this integration does not.

Scene examples​

  • Cinema mode: when Netflix, Prime Video or Disney+ comes to the screen after 8 pm, dim the living room lights to 20 %.
  • Pause, lights up: when playback pauses on the living room TV, turn the lights to 60 %; when it starts again, back to 20 %.
  • Morning news: at 7:30 on weekdays, turn the kitchen TV on and open the address of a news stream on YouTube.
  • Bedtime for the kids: when YouTube Kids comes to the screen of the children's TV after 9 pm, send a message to the parents, or put the TV in standby.

Troubleshooting​

  • "Never reached": check the address, that the device is on, and that network debugging is enabled. Some TVs (Philips) accept the first authorization only over Wi-Fi: authorize once over Wi-Fi, then the wired connection works too.
  • "Not allowed yet": accept the question on the screen and tick "Always allow", or run Connect the devices with the screen on. Android 11+ forgets an authorization unused for seven days: Developer options → "Disable adb authorization timeout".
  • "Wireless debugging (pairing) port": the address points to the port of Android 11 wireless debugging, not to network debugging on 5555 (see Requirements).
  • The volume always shows 100 %: on a box connected by HDMI, the volume is the TV's (HDMI-CEC), and the box outputs a fixed volume. Use the Volume +/- keys, which the box forwards to the TV.
  • An application is missing from the list: it has no home screen entry (a service, an input). Use the "Open an application" action with its package name.
  • Another ADB client cannot connect: some devices accept one ADB connection at a time. While the screen is on, Gladys keeps one open.
  • The device does not wake up from standby: in deep standby some TVs turn their network off, so nothing can reach them. Enable the network standby option of the TV ("Wake on network", "Quick start", "Remote start").
  • More details: set LOG_LEVEL=debug on the integration to see every read in its logs.

To remove the authorization of Gladys from a device: Developer options → "Revoke USB debugging authorizations".

Limits​

  • Developed without the hardware: the formats of the device answers come from the Home Assistant libraries and the Android sources, and differ across models and versions. Feedback welcome.
  • No automatic discovery: the devices do not announce their network debugging port reliably, and the integration cannot listen to the local network by itself. Type the addresses.
  • A device whose network sleeps in standby cannot be turned on by Gladys.
  • The playback state depends on the application publishing it (Netflix, YouTube, Plex, Spotify, VLC do; some do not).
  • No HDMI input switching, no channel, no screenshot, no free shell command.
  • Android 11+ wireless debugging (pairing code) is not supported.

Security and privacy​

  • The key of Gladys (an RSA key, like the one of the adb tool) is created at the first start and kept in the data volume of the integration (/data/adbkey). It never leaves it and never appears in the logs. Anyone who holds it, and reaches the device on the network, can control the device: keep your Gladys backups private.
  • /data/androidtv-adb.json keeps the identified devices: address, serial number or MAC address, model, Android version, installed applications.
  • The integration only sends the fixed commands described here, reads the state of the device and never reads your files. All traffic stays on your local network.

Configuration settings​

These are the settings Android TV / Fire TV (ADB) asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Before you startsectionNoOn the TV or box: enable the developer options (click 7 times on the build number), then network debugging (Fire TV: ADB debugging). Type its IP address below and save: the screen asks "Allow debugging?". Tick "Always allow" and accept. Complements the Android TV Remote integration: ADB also works on Fire TV, opens any app and reads the app on screen.
Device IP addressesstringNoOne address per TV or box, separated by commas. Port 5555 by default (add :port otherwise). Give each device a fixed address in your router.
Refresh while on (seconds)numberNoHow often a device that is on is read (5 to 60 s). In standby, once a minute.
Language of the feature namesselectNoNames given to the features when a device is added, and texts of the scene events.

How to install Android TV / Fire TV (ADB) in Gladys​

  1. In Gladys, open Integrations: Android TV / Fire TV (ADB) appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-androidtv-adb:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-androidtv-adb.

Android TV / Fire TV (ADB) requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

Android TV / Fire TV (ADB) is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
