Airthings smart home integration, free and open source
Radon, CO₂, VOC, particles, temperature and humidity of your Airthings sensors.
Published by guim31
- Devices
- Version 1.0.1
- Requires Gladys >=5.1.0
- ★ 0
Brings your Airthings air quality monitors into Gladys: radon, CO₂, VOC, particles, temperature, humidity, pressure, battery and the age of the last measurement, read from the official Airthings cloud API. A dashboard widget shows the air of every room at a glance, with a clear colour code for radon.
Radon is a natural radioactive gas, the second cause of lung cancer after smoking, and a real concern in granite regions (Brittany, the Massif Central, Corsica, the Vosges…). In France, the reference level is 300 Bq/m³ (annual average).
Developed without the hardware: feedback welcome. This integration was written from the official API specification and published answers, without an Airthings sensor nor account. If something looks wrong, please open an issue: https://github.com/guim31/gladys-airthings/issues
This integration is not affiliated with Airthings. Airthings, Wave, View and Space are trademarks of Airthings ASA.
Requirements
- Gladys Assistant 5.1.0 or later.
- One or more Airthings sensors (Wave, Wave Plus, Wave Mini, Wave Radon, Wave Enhance, View Plus, View Radon, View Pollution, Space…) registered in the Airthings app. The Wave sensors upload through an Airthings Hub, a View Plus, or the phone app over Bluetooth: a Wave that only syncs with the phone is updated only when the app is open nearby.
- An Airthings API client (free): its client id and secret. One client per Airthings account.
- Internet access for Gladys: the data comes from the Airthings cloud, not from the sensors directly.
Configuration
- Open the Airthings API dashboard (https://consumer-api-doc.airthings.com/dashboard) and sign in with your Airthings account.
- Create an API client, then copy its client id and client secret.
- In Gladys, open Integrations, install Airthings (Integrations → Install from GitHub, or from the store), then fill in its configuration:
- Client id and Client secret;
- Refresh interval: 5 minutes is recommended (2 to 60 minutes);
- Radon reference level: from this level the widget shows radon in red (300 Bq/m³ in France and the EU; 148 Bq/m³ is the US EPA action level; 100 Bq/m³ the WHO recommendation);
- Language of the feature names: the names given to new features (French by default).
- Press Test the connection: it lists the sensors found and the API requests used this hour.
- Open the Discovery tab of the integration and add the sensors you want in Gladys.
Devices and features
One Gladys device per Airthings sensor (the hub, which measures nothing, is left out). Each device only has the features its sensor really reports:
| Feature (English names) | Unit | Sensors |
|---|---|---|
| Radon (short term) | Bq/m³ | Wave, Wave Plus, Wave Radon, View Plus, View Radon, Corentium Home 2 |
| Radon (long term) | Bq/m³ | when the API sends it |
| CO₂ | ppm | Wave Plus, Wave Enhance, View Plus, View CO2, Space |
| VOC | ppb | Wave Plus, Wave Mini, Wave Enhance, View Plus |
| PM1 | µg/m³ | View Plus, View Pollution |
| PM2.5 | µg/m³ | View Plus, View Pollution |
| PM10 | µg/m³ | when the API sends it |
| Temperature | °C | most sensors |
| Humidity | % | most sensors |
| Pressure | hPa | Wave Plus, Wave Enhance, View Plus |
| Light | lux | Wave Enhance, when the API sends it |
| Noise | dBA | Wave Enhance, when the API sends it |
| Battery | % | battery-powered sensors |
| Measurement age | minutes | every sensor: how old its last measurement is |
The short-term radon is the average of the last 24 hours. Gladys has no radon category: the radon features are published as counters in Bq/m³, and the widget gives the colour code. Gladys has no PM1 category either: PM1 is published as a PM2.5 feature named "PM1".
All features are read-only: nothing can be controlled.
Widget
Air quality (dashboard → Edit → add a widget → Airthings):
- Every room (setting left empty): one row per sensor, its dot coloured by the worst of its values, the rooms that need attention first; plus the highest radon and the highest CO₂ of the house.
- One sensor (chosen in the setting): five tiles (radon, CO₂, PM2.5, temperature, humidity first), the radon curve of the last week once the device is added to Gladys, the radon verdict, the other values, the battery and the age of the measurement.
Colours: radon green under 100 Bq/m³ (WHO), orange up to the reference level of the configuration, red from it. CO₂ 800 / 1000 ppm, VOC 250 / 2000 ppb, particles 10 / 25 µg/m³, humidity good from 30 to 60 %: the thresholds of the Airthings apps.
Triggers and actions
The integration declares no scene trigger nor scene action of its own: the states of the devices already cover every use with the triggers of Gladys ("a device value goes above a threshold"). The only action is the Test the connection button of the configuration screen.
Scene examples
- Radon above the reference: trigger "Radon (short term) of Cellar above 300", action: send a message "Air the cellar: radon above 300 Bq/m³" and switch on the ventilation (a smart plug).
- Air the bedroom: trigger "CO₂ of Bedroom above 1000", condition: someone at home, action: a notification "Open the window of the bedroom".
- Sensor silent: trigger "Measurement age of Living room above 180" (three hours without upload), action: a message "Check the Airthings hub or the batteries".
- Batteries: trigger "Battery of Bedroom below 15", action: a message to buy batteries.
Refresh and API quota
The Airthings Consumer API allows 120 requests per hour per API client. One reading of the whole account is one request (50 sensors per page), plus the device list once an hour and a new token every few hours: at 5 minutes the integration uses about 13 requests an hour. It never goes beyond 100 an hour on its own, and stops until the time the API gives when it answers "too many requests".
The sensors upload every 2.5 minutes (View series) to 5 minutes or more (Wave series, through a hub or the phone): reading more often only reads the same values again. The integration reads the cloud on its own timer, and publishes a value to Gladys only when it changes (and at least every 6 hours). A sensor added in Gladys gets its values at once, from the last reading.
Stored in the container: the access token, the Airthings account id and the features seen per sensor (under /data). The client secret stays in the Gladys configuration.
Troubleshooting
- "client id or secret refused": copy them again from the Airthings API dashboard (no space); a deleted API client must be recreated. The integration tries again every 30 minutes, or at once after you save the configuration.
- "request quota of the Airthings API reached": another tool uses the same API client, or the interval is short. Readings resume on their own; choose a longer interval.
- A sensor shows no recent value: look at its Measurement age. A Wave needs a hub, a View Plus or the phone app nearby to upload; the batteries may be flat.
- A sensor is missing: it must be registered in the Airthings app with the same account as the API client; press Search in the Discovery tab.
- More details: restart the container with
LOG_LEVEL=debug. The logs never contain the client id, the secret nor the token.
Limits
- Cloud only: no local Bluetooth reading of the sensors (the Gladys container has no Bluetooth).
- The values are those of the last upload of the sensor: up to 5 minutes or more behind for a Wave.
- The mold and virus risk indexes of some sensors are not read (Gladys has no feature for them), nor the Renew air purifier controls.
- The names of the features are frozen when the device is added in Gladys.
- Developed without the hardware: feedback welcome at https://github.com/guim31/gladys-airthings/issues
Configuration settings
These are the settings Airthings asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Airthings API client | section | No | Open the Airthings API dashboard (link below), sign in with your Airthings account, create an API client, then copy its client id and secret here. Free, one client per account. Not affiliated with Airthings. |
| Client id | string | Yes | |
| Client secret | secret | Yes | |
| Refresh interval | select | No | The sensors upload every 2.5 to 5 minutes or more, and the API allows 120 requests per hour: 5 minutes is enough. |
| Radon reference level | select | No | From this level the widget shows radon in red; from 100 Bq/m³ (WHO) in orange. |
| Language of the feature names | select | No | Gladys does not tell an integration your language: pick the one of the names given to new features. |
How to install Airthings in Gladys
- In Gladys, open Integrations: Airthings appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/guim31/gladys-airthings:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/guim31/gladys-airthings.
Airthings requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
About external integrations
Airthings is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
