AirGradient smart home integration, free and open source
AirGradient air quality monitors on the local network: CO₂, PM2.5, VOC, temperature, humidity.
Published by guim31
- Devices
- Version 1.0.1
- Requires Gladys >=5.1.0
- ★ 0
This integration brings the AirGradient air quality monitors into Gladys: the AirGradient ONE (indoor), the Open Air (outdoor), the DIY kits and the AirGradient Go. It reads them on your local network, over the local API of their firmware: no account, no cloud, no API key.
Developed without the hardware: feedback welcome. The integration was written from the AirGradient firmware source, the documentation of its local API and the real answers published with the
airgradientPython library and the Home Assistant integration. It has not been tried on a real monitor yet: tell us on the Gladys forum what works and what does not.
This integration is not affiliated with AirGradient.
What you get
- One device per monitor, found automatically on your network (mDNS), or added by its IP address.
- Its measurements, refreshed every minute: PM1, PM2.5, PM10, CO₂, temperature, humidity, TVOC index, NOx index, 0.3 µm particle count, Wi-Fi signal (and the battery of the Go). Only what your model measures: an Open Air without CO₂ sensor gets no CO₂ feature.
- The corrected values when the firmware provides them (PM2.5 with the EPA correction, temperature and humidity of the Open Air): they are the ones the monitor shows.
- As an option, the monitor settings from Gladys: display brightness, LED bar brightness, LED bar mode and display temperature unit (AirGradient ONE, DIY kits).
- An "Air quality" dashboard widget: the live readings and the air quality in colour.
- A scene trigger when a monitor stops answering, and a scene action to calibrate the CO₂ sensor (disabled by default).
Requirements
- Gladys Assistant 5.1.0 or later.
- An AirGradient monitor on firmware 3.1 or later (3.0.10 for the local API, 3.1.4 for the corrected PM2.5), connected to the same network as Gladys, or to a network Gladys can reach.
- Nothing else: the local API needs no password.
To find the IP address of a monitor: your router's list of connected devices (the monitor is
called airgradient_<serial number>), or the AirGradient dashboard, under the monitor's details.
Configuration
Install the integration from Integrations → Install from the store (or Install from GitHub), then open its Configuration tab.
Settings
| Setting | Default | What it does |
|---|---|---|
| Monitor IP addresses | empty | Optional. Addresses the automatic discovery does not find, separated by commas (192.168.1.50). |
| Refresh interval | 1 minute | How often each monitor is read: 30 seconds, 1, 2 or 5 minutes. |
| Monitor settings from Gladys | No | Adds the display and LED bar settings to the devices (see below). |
| CO₂ calibration from scenes | Not allowed | Allows the "Calibrate the CO₂ sensor" scene action. |
| Language of the feature names | French | Names given to the features of new devices. |
Finding the monitors
The monitors announce themselves on the network (mDNS, service _airgradient._tcp). The
integration runs in a container that cannot hear these announcements: Gladys listens for it and
passes them on. Open the Discover tab, then add the monitors you want.
If a monitor is missing (another network, a VLAN, mDNS filtered by the router), type its IP address in Monitor IP addresses. The Search for monitors button looks for them again and lists what it found. A monitor that changes address (DHCP) is followed by its serial number: its device stays the same. Giving it a fixed address in your router is still the most reliable.
Monitor settings from Gladys
With Monitor settings from Gladys set to Yes, the devices of the AirGradient ONE and of the DIY kits get extra features:
- Display brightness and LED bar brightness (0 to 100 %, the LED bar on the ONE only);
- LED bar mode: off, CO₂ or PM2.5 (ONE only);
- Display temperature unit: °C or °F, for the monitor's screen only — Gladys always receives the temperature in °C and shows it in your own unit.
After changing this setting, click Update on the monitor in the Discover tab.
A monitor set up on the AirGradient dashboard may take its settings from the cloud only. Gladys then cannot change them: run Use local settings in the Configuration tab and choose the monitor. From then on, the monitor only takes its settings from the local network, and the settings of the AirGradient dashboard no longer apply to it.
Devices
Each monitor is a device named after its model and the end of its serial number (for example "AirGradient ONE 12f5"): rename it as you like.
| Feature | Unit | Notes |
|---|---|---|
| PM1 | µg/m³ | Gladys has no PM1 category: it is shown with the PM2.5 icon. |
| PM2.5 | µg/m³ | Corrected value when the firmware provides it. |
| PM10 | µg/m³ | |
| CO₂ | ppm | ONE, Open Air with CO₂ sensor, Go, most DIY kits. |
| Temperature | °C | Corrected value on the Open Air. |
| Humidity | % | Corrected value on the Open Air. |
| TVOC index | 1 to 500 | Sensirion index: 100 is the average of the last day, more is worse. |
| NOx index | 1 to 500 | Sensirion index: 1 is the normal level, more means nitrogen oxides. |
| 0.3 µm particles | per decilitre | Raw particle count of the PM sensor. |
| Battery | % | AirGradient Go only. |
| Wi-Fi signal | dBm | -30 is excellent, -80 is weak. |
The values are rounded (temperature to 0.1 °C, humidity to 1 %, particles to 0.1 µg/m³) and only sent to Gladys when they change; an unchanged value is sent again every 12 hours. The device shows a "local" badge, or "unreachable" when the monitor does not answer.
Dashboard widget
Add the Air quality widget (AirGradient) to a dashboard and choose a monitor in its settings. It shows the live CO₂, PM2.5, temperature and humidity, and a coloured status:
| Level | CO₂ (ppm) | PM2.5 (µg/m³) |
|---|---|---|
| Good | up to 800 | up to 9 |
| Moderate | up to 1000 | up to 35 |
| Poor | up to 1500 | up to 55 |
| Very poor | above 1500 | above 55 |
These are the colours of the AirGradient LED bar (for PM2.5, the US EPA breakpoints; the WHO 24-hour guideline, 15 µg/m³, is in the "moderate" band). The overall air quality is the worst of the two.
Scene trigger
AirGradient monitor not answering: a monitor stopped answering (three readings in a row, three minutes with the default interval). Filter on a monitor, or leave it empty for any monitor. Variables: the monitor name and its IP address. It fires once, when the monitor is lost; its last values stay in Gladys.
There is no trigger for "CO₂ above 1000": use the usual device trigger of Gladys on the CO₂ feature, with your own threshold.
Scene action
Calibrate the AirGradient CO₂ sensor: the sensor takes its current reading as 400 ppm, the level of fresh outdoor air. It is refused until you set CO₂ calibration from scenes to Allowed. Only run it with the monitor outdoors (or by a wide open window) for several minutes: indoors, every later reading would be too low. The CO₂ sensor of the monitors also recalibrates itself over a few days (automatic baseline calibration): most users never need this action.
Scene examples
- Air the room: when the CO₂ of the bedroom goes above 1200 ppm, send a message "Open the window" — and when it goes back below 800 ppm, "You can close it".
- Wildfire smoke or pollution: when the PM2.5 of the Open Air goes above 35 µg/m³, close the shutters and turn the air purifier on.
- Monitor lost: with the trigger "AirGradient monitor not answering", send a message with
{{triggerEvent.data.name}}and its address. - Night mode (with the settings): at 10 pm, set the display brightness and the LED bar brightness of the ONE to 0; at 7 am, set them back to 80.
Troubleshooting
- No monitor in the Discover tab: check that the monitor is connected to Wi-Fi (its screen shows the readings, not a setup message), then type its IP address in Monitor IP addresses and click Search for monitors. The report says whether the automatic discovery is available.
- "does not answer": the monitor is off, out of Wi-Fi range, or has a new address. Open
http://<IP address>/measures/currentin a browser of the same network: it should show the readings in JSON. Firmware older than 3.0.10 has no local API: update it from the monitor. - A setting is refused, "only accepts settings from the AirGradient cloud": run Use local settings.
- A value is missing right after a restart of the monitor: the sensors need up to a minute before their first reading; the value appears at the next refresh.
- Logs: the Supervision page of Gladys shows the logs of the integration. They are quiet on
purpose: a line when a monitor is found, lost or back, and one per action. Set the
LOG_LEVEL=debugvariable to see every reading.
Limits
- The integration reads the local API only. The AirGradient cloud API (with a token) is not supported: a monitor must be reachable from Gladys on the network.
- The local API has no password: anyone on your network can read a monitor, and change its settings if it accepts local settings. This is how the firmware works.
- The settings of the AirGradient Go (newer API) and of the Open Air (no screen) are not offered; their measurements are.
- The TVOC and NOx indexes are shown with the "Sensirion VOC index" category: Gladys has no NOx category. PM1 uses the PM2.5 category.
- The readings are averages computed by the monitor; refreshing more often than every 30 seconds would only repeat them. The local API has no quota, but the monitor is a small device: one reading a minute is what Home Assistant does too.
- The settings changed from the AirGradient dashboard are not seen by Gladys until the next reading.
Configuration settings
These are the settings AirGradient asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Finding your monitors | section | No | AirGradient monitors (ONE, Open Air, DIY kits, firmware 3.1 or later) on the same network as Gladys are found automatically (mDNS): open the Discover tab. If one is missing, enter its IP address below. |
| Monitor IP addresses | string | No | Optional, separated by commas. Only needed for the monitors automatic discovery does not find. |
| Refresh interval | select | No | How often each monitor is read. The monitors average their sensors over about a minute. |
| Monitor settings from Gladys | select | No | Adds the display and LED bar brightness, the LED bar mode and the display temperature unit to the devices (ONE and DIY kits). Click Update in the Discover tab afterwards. |
| CO₂ calibration from scenes | select | No | The calibration takes the current reading as 400 ppm: only run it with the monitor in fresh outdoor air, or every later reading is wrong. |
| Language of the feature names | select | No | Names given to the features of new devices (CO₂, Temperature, Humidity...). |
How to install AirGradient in Gladys
- In Gladys, open Integrations: AirGradient appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/guim31/gladys-airgradient:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/guim31/gladys-airgradient.
AirGradient requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
