Yoto Player Advanced Smart-Home-Integration, kostenlos und Open Source
Control a Yoto Player: night light, volume, cards and sensors.
Veröffentlicht von b3n0
- Geräte
- Version 1.0.6
- Erfordert Gladys >=5.3.0
- ★ 0
Die Dokumentation dieser Integration wird von ihrem Autor geschrieben und ist bisher nur auf Englisch verfügbar.
This integration adds every Yoto Player of a Yoto account to Gladys Assistant: night light, volume, sensors, and card playback from a scene. Gladys 5.3 or later is required.
What you get
After the account is linked, each player shows up in the Discovery tab. Updating a player that is already added (the Update button on that tab) adds the new features.
Controls:
- Night light — on/off and colour of the light ring for the profile the
player is in (day or night). Off sends Yoto's
#0colour. - Brightness — screen brightness of that same profile, from 0 to 100.
The value
autois shown as 100; moving the slider stores a fixed number. - Volume — from 0 to 100%.
- Day max volume and Night max volume — the limits, shown from 0 to 100%. The player stores them on its 17-step knob: the slider snaps to the nearest step.
Read-only:
- Battery, Charging (plugged in, including a full battery), Online, Wi-Fi signal, Ambient light, Temperature.
- Playing and Card playing. The title, the author and the cover feed Gladys' music player. The track and the position are not available: the API does not provide them.
Dashboard
Two widgets: Yoto players (every player of the account) and Yoto player (one player, with the 24 h battery curve). They show the last reading. Refresh reads the player immediately.
Scenes
Triggers:
- A card starts — filters: player, exact title. Variables: player name, title, id.
- A player stops playing — filter: player.
- Battery low — under 20%, once, until the player is plugged in or the level climbs back above 25%.
Actions:
- Play a Yoto card — player, card id (for example
5WsQg), track index (0 is the first track of chapter 01). - Read a Yoto player — reads now and passes battery, volume, card, temperature and night light to the next steps.
- Refresh all Yoto players.
The first reading after a start does not fire a scene.
Configuration
Open the Yoto applications site, create an application, then open Edit Application.
- Application Type: leave Public Client.
- Allowed Callback URLs: erase the example and put only
https://my.gladysassistant.com/redirect/oauth. - Scopes: tick
family:devices:control,family:devices:manage,family:viewandoffline_access. Rights already marked Included automatically are enough, includingfamily:library:viewfor card titles. Do not tickfamily:library:manageoruser:content:manage. - Leave Description, Allowed Logout URLs, Application Logo and Application Privacy Policy URL empty.
- Click Update Application.
- In Gladys, copy the Client ID into Identifier. Leave Secret empty, save, then click Link my Yoto account. Sign in with the family account.
- Click Test the Yoto connection. Players appear in the Discovery tab.
The connection stays on by itself. Link the account again only if the Yoto password changes, or if the application is removed from the account.
Player update is how long to wait between readings. 300 means 5 minutes, and Gladys cannot go below one minute. Ask the player for a fresh status asks the player to report before the reading. Turn it off if the player wakes too often.
Konfigurationseinstellungen
Diese Einstellungen fragt Yoto Player Advanced in seinem Konfigurationsbildschirm in Gladys ab.
| Einstellung | Typ | Pflichtfeld | Beschreibung |
|---|---|---|---|
| Getting started | section | Nein | On the Yoto site, open Edit Application and keep Application Type on Public Client. In Allowed Callback URLs, erase the example and put only https://my.gladysassistant.com/redirect/oauth. Under Scopes, tick family:devices:control, family:devices:manage, family:view and offline_access. Rights already marked Included automatically are enough. Leave Description, Allowed Logout URLs, Application Logo and Application Privacy Policy URL empty, then click Update Application. Copy the Client ID into Identifier, save, then click Link my Yoto account. |
| Identifier | string | Ja | The Client ID copied from your Yoto application. |
| Secret | secret | Nein | Leave empty. A Public Client has no secret. |
| Link my Yoto account | oauth2 | Nein | |
| Player update (seconds) | number | Nein | How long to wait before reading the player again. 300 means 5 minutes. |
| Ask the player for a fresh status | boolean | Nein | Before each reading, ask the player to report. Turn off if the player wakes too often. |
So installierst du Yoto Player Advanced in Gladys
- Öffne in Gladys Integrationen: Yoto Player Advanced erscheint im Katalog neben den nativen Integrationen, mit einem Community-Badge.
- Klicke auf Installieren. Gladys lädt das Docker-Image (
ghcr.io/b3n0/adavanced-yoto:1.0.6) herunter, startet es in einer vom Kern isolierten Sandbox und erzeugt die Oberfläche der Integration (Geräte, Erkennung und Konfiguration). - Öffne den Bildschirm Konfiguration der Integration, fülle die Einstellungen aus und speichere.
- Du kannst sie auch direkt über die URL ihres Repositorys installieren: https://github.com/b3n0/Adavanced-Yoto.
Yoto Player Advanced benötigt Gladys >=5.3.0. Der Katalog in Gladys wird stündlich aktualisiert, eine neue Version ist also spätestens eine Stunde nach ihrer Veröffentlichung verfügbar.
Du nutzt Gladys noch nicht? Es ist kostenlos und Open Source: folge der Installationsanleitung, um loszulegen.
Über externe Integrationen
Yoto Player Advanced ist eine externe Integration: eine Community-Integration, die als Docker-Container verpackt und auf GitHub veröffentlicht wird. Gladys installiert sie mit einem Klick und führt sie in einer vom Kern isolierten Sandbox aus. Sie wird von b3n0 veröffentlicht und gepflegt, nicht vom Gladys-Kernteam.
