Victron Energy GX Smart-Home-Integration, kostenlos und Open Source
Victron GX (Cerbo, Venus OS): battery, solar, inverter, meters and EV charger over local MQTT.
Veröffentlicht von LM1LC3N7
- Geräte
- Version 0.1.1
- Erfordert Gladys >=5.0.0
- ★ 0
Die Dokumentation dieser Integration wird von ihrem Autor geschrieben und ist bisher nur auf Englisch verfügbar.
This integration brings your Victron Energy installation into Gladys through its GX device (Cerbo GX, Ekrano GX, Venus GX, or Venus OS on a Raspberry Pi): batteries, solar chargers, inverter/charger, meters and EV charging station, read live on your local network. It talks to the MQTT broker built into the GX device: nothing goes through the Internet or VRM. Unofficial, not affiliated with Victron Energy.
Development version (0.1). Developed against the official MQTT documentation of Victron and simulated installations, not yet tested on every real system. Your feedback is welcome on the GitHub repository.
What you get
Each Victron device found on the GX becomes a Gladys device in the Discovery tab, named as on the GX (custom name, else product name).
| Victron device | In Gladys |
|---|---|
| Battery monitor (SmartShunt, BMV…) | state of charge, charge and discharge power, voltage, current, temperature, charged/discharged energy |
| Solar charger (MPPT) | PV power, yield today, total production, charge state (Bulk, Absorption, Float…) |
| Inverter/charger (MultiPlus, Multi RS…) | AC input and output power, state, mode (on, off, charger only, inverter only) |
| Grid meter | grid power (positive when importing, negative when exporting), imported and exported energy |
| AC load meter, heat pump | power and energy |
| PV inverter (Fronius…) | PV power, total production, status |
| EV charging station | charging power, energy, connector and charging state, detailed status |
| System overview | AC consumption, grid power (without a grid meter), system state, ESS minimum SOC |
The values use the Gladys energy categories (battery storage, energy production, grid, home output, energy sensor): they show up in the energy dashboards like those of any other brand.
What you can control: the mode of the inverter/charger (unless a VE.Bus BMS holds it), and the minimum state of charge of the ESS (the battery reserve kept for a power cut), in % — for example "raise the reserve to 80 % when a storm is announced".
Requirements
- A GX device with Venus OS 3.20 or later.
- MQTT turned on on the GX: Settings → Services → MQTT (on recent versions, "Local MQTT" set to on). Port 1883 (plain) or 8883 (TLS), depending on the network security profile of the GX.
- The GX reachable from the Gladys machine (same local network, fixed IP address recommended).
Installation
- In the configuration, type the address of the GX device: its IP address
(for example
192.168.1.50, which meansmqtt://192.168.1.50:1883). - With the "Secured" or "Weak" network security profile
(Settings → General → Network security profile), the GX only accepts TLS
with its password: type
mqtts://192.168.1.50:8883, any user name (for examplegladys) and the password of the GX. With the "Unsecured" profile, leave the user name and the password empty. - Click Test the connection: the GX and its devices are listed.
- Open the Discovery tab and add the devices you want.
The VRM portal ID is read automatically from the GX: type it only if several GX devices share the same broker.
Options
| Option | Default | Purpose |
|---|---|---|
| VRM portal ID | empty | read from the GX; only for a broker shared by several GX devices |
| Verify the TLS certificate | off | the GX uses its own certificate: turn on only if you installed a trusted one |
| Minimum interval of a reading | 10 s | the GX publishes every second: Gladys records the last value at this pace |
States (charge state, mode, EV charging state) are never delayed. Gladys accepts 300 states per minute per integration: the integration rounds the values, only sends those that change, and stays under that limit.
How it works
The GX device only publishes its values while a client keeps it awake: the
integration sends a keep-alive on R/<portal ID>/keepalive every 30 seconds,
and asks for every value again at each connection and each time Gladys scans
the devices. It subscribes to the topics it needs only. A device that leaves
the GX (a PV inverter at night) shows as unreachable on its badge, and
comes back by itself.
Troubleshooting
- "No GX device publishes on this broker": MQTT is off on the GX, or the address is the one of another broker.
- "refused the connection": with the "Secured" profile, use
mqtts://on port 8883 and the password of the GX device. - "does not answer": the GX runs a Venus OS older than 3.20, or the VRM portal ID typed in the configuration is wrong (leave it empty).
- The mode cannot be changed: a VE.Bus BMS or a Digital Multi Control holds the switch of the inverter/charger; the GX reports it and Gladys shows the mode read-only.
- No "ESS minimum SOC": the system is not an ESS (Settings → ESS).
Privacy
Everything stays on your network: the integration only talks to the GX device. The password is stored as a secret by Gladys and never appears in the logs.
Disclaimer
Unofficial integration, not affiliated with Victron Energy. Victron Energy, Cerbo GX, Venus OS and VRM are trademarks of Victron Energy B.V. Changing the mode of an inverter/charger or the ESS reserve acts on a real power installation: use it knowingly.
Konfigurationseinstellungen
Diese Einstellungen fragt Victron Energy GX in seinem Konfigurationsbildschirm in Gladys ab.
| Einstellung | Typ | Pflichtfeld | Beschreibung |
|---|---|---|---|
| Your Victron installation in Gladys | section | Nein | Reads your Victron Energy GX device (Cerbo GX, Ekrano GX, Venus OS on a Raspberry Pi...) on your local network, through its own MQTT broker: battery, solar chargers, PV inverters, inverter/charger (state and mode), grid and AC load meters, EV charging station, and the ESS minimum state of charge. On the GX device, turn on MQTT (Settings > Services > MQTT, Venus OS 3.20 or later), then type its IP address below. Nothing goes through the Internet nor VRM. Unofficial, not affiliated with Victron Energy. |
| GX device address | string | Ja | The IP address of the GX device (MQTT on port 1883). With the "Secured" network security profile of the GX: mqtts://address:8883. |
| User name | string | Nein | Only with a password: the GX device does not check it, any name works (for example gladys). |
| Password | secret | Nein | The password of the GX device, for the "Secured" and "Weak" network security profiles. |
| VRM portal ID (optional) | string | Nein | Read automatically from the GX device. Only needed when several GX devices share the same broker (Settings > VRM online portal on the GX). |
| Verify the TLS certificate of the GX device (mqtts) | boolean | Nein | The GX device uses its own certificate, which no public authority signed: leave off, unless you installed a trusted one. |
| Minimum interval between two readings of a measurement (s) | number | Nein | The GX device publishes every second: Gladys keeps the last reading at this pace. States and modes are never delayed. |
So installierst du Victron Energy GX in Gladys
- Öffne in Gladys Integrationen: Victron Energy GX erscheint im Katalog neben den nativen Integrationen, mit einem Community-Badge.
- Klicke auf Installieren. Gladys lädt das Docker-Image (
ghcr.io/lm1lc3n7/gladys-victron:0.1.1) herunter, startet es in einer vom Kern isolierten Sandbox und erzeugt die Oberfläche der Integration (Geräte, Erkennung und Konfiguration). - Öffne den Bildschirm Konfiguration der Integration, fülle die Einstellungen aus und speichere.
- Du kannst sie auch direkt über die URL ihres Repositorys installieren: https://github.com/LM1LC3N7/gladys-victron.
Victron Energy GX benötigt Gladys >=5.0.0. Der Katalog in Gladys wird stündlich aktualisiert, eine neue Version ist also spätestens eine Stunde nach ihrer Veröffentlichung verfügbar.
Du nutzt Gladys noch nicht? Es ist kostenlos und Open Source: folge der Installationsanleitung, um loszulegen.
Über externe Integrationen
Victron Energy GX ist eine externe Integration: eine Community-Integration, die als Docker-Container verpackt und auf GitHub veröffentlicht wird. Gladys installiert sie mit einem Klick und führt sie in einer vom Kern isolierten Sandbox aus. Sie wird von LM1LC3N7 veröffentlicht und gepflegt, nicht vom Gladys-Kernteam.
