Hilo (Hydro-Québec) Smart-Home-Integration, kostenlos und Open Source
Hilo by Hydro-Québec: peak challenges, thermostats, switches, lights and live power.
Veröffentlicht von LM1LC3N7
- Geräte
- Version 0.1.1
- Erfordert Gladys >=5.1.0
- ★ 0
Die Dokumentation dieser Integration wird von ihrem Autor geschrieben und ist bisher nur auf Englisch verfügbar.
This integration brings your Hilo home, the smart-home service of Hydro-Québec, into Gladys, live: the challenges (the peak events Hilo manages for you: pre-heat, reduction, recovery, rewards) as sensors and scene triggers, and the Hilo devices (thermostats, plugs, switches and dimmers, water heater controllers, smart meter, weather stations) with their power. It uses your Hilo account. Unofficial, not affiliated with Hilo or Hydro-Québec.
Development version (0.1). Written from the protocol of python-hilo and of the Hilo integration of Home Assistant (dvd-dev/hilo), and tested with simulated answers, not yet with a real Hilo account. Feedback is welcome on the GitHub repository.
What you get
| Device | In Gladys |
|---|---|
| Hilo challenges | challenge (text), challenge announced, pre-heat, reduction and recovery in progress (0/1), reduction start and end, rewards ($) |
| Thermostat (Hilo, Sinopé, Mysa…) | temperature, setpoint (settable), humidity, power, energy |
| Plug, load controller | on/off (settable), power, energy |
| Water heater controller | on/off (settable), water temperature, power, energy |
| Switch, dimmer, bulb | light (settable), brightness (settable), power, energy |
| Smart meter | power of the house, energy |
| Weather station (Netatmo) | temperature, humidity, CO2, noise, pressure, battery |
- Live: the values come through Hilo's real-time link (the one of the app), not by polling.
- Commands: the thermostat setpoints, the on/off of plugs, switches and water heaters, the brightness of dimmers, when Hilo allows setting them. The value shows at once, Hilo confirms it next.
- Energy: Hilo gives the live power but no energy counter. The integration therefore computes a kWh index for each device measuring its power (power times time, like the "Riemann" meters of Home Assistant), which Gladys turns into a 30-minute consumption and a cost. It is an estimate: it only moves while the live link works. See below how to use it with the Hydro-Québec integration.
- Badges: a device Hilo reports disconnected turns
unreachable. - The OneLink smoke detector and the gateway have nothing to show and are not offered.
Installation
- Install the integration from the Gladys store.
- In the Configuration tab, click Connect (Hilo account): the Hilo sign-in page opens. Sign in with your Hilo account.
- Hilo then opens a Home Assistant page (my.home-assistant.io): this is
expected, it is the only address Hilo accepts for this app (the one of the
Home Assistant integration, which the Gladys integration reuses). You do
not need Home Assistant: copy the whole address of that page from the
browser's address bar (it starts with
https://my.home-assistant.io/redirect/oauth?and containscode=). - Back in Gladys, open the Finish the sign-in action, paste the address and submit, within 30 minutes. The status turns "Connected to Hilo".
- Open the Discovery tab and add the devices you want, including Hilo challenges.
The session is kept in the /data volume of the integration: a restart does
not ask to sign in again. Hilo renews the session as long as the integration
runs; if Hilo refuses it one day (expired session, changed password), the
status says so, the Hilo sign-in needed trigger fires, and steps 2 to 4
are enough.
Options
| Option | Default | Role |
|---|---|---|
| Hydro-Québec rate | Automatic | Rate D with winter credits (CH) or Flex D, to follow the challenge details when Hilo does not say it |
| Anticipation before the pre-heat (h) | 0 (none) | An "anticipation" phase that many hours before the pre-heat, for an earlier scene trigger (0 to 24) |
| Lock the setpoints during a reduction | no | Refuses setpoint changes from Gladys (dashboard, scenes) during the reduction, so the challenge is not spoilt |
| Language of the feature names | French | Names of the features of the devices added from now on, and the challenge texts |
Actions: Finish the sign-in, Test the connection (account, location, number of devices, live link, next challenge) and Sign out (forgets the session).
Challenges
A Hilo challenge follows the phases Hilo publishes (usually the day before):
- announced: the challenge is planned;
- anticipation (if configured): that many hours before the pre-heat;
- pre-heat: Hilo heats a bit more before the peak;
- reduction: the peak, Hilo lowers the heating; the consumption of this period is what counts;
- recovery: back to normal, gradually;
- completed: after the recovery; the final reward may come later.
The Hilo challenges device shows the next challenge (or the one in progress):
- Challenge: a text, e.g. "Challenge on Sun, Jan 4: reduction 4:00 p.m. – 8:00 p.m." or "Reduction until 8:00 p.m.";
- Challenge announced, Pre-heat in progress, Reduction in progress, Recovery in progress: 1 or 0, for scene conditions ("if a reduction is in progress…");
- Next reduction start / end: in Québec time;
- Estimated reward (during the challenge), Reward of the last challenge, Rewards of the season (in $, winter credits of Rate D; Flex D has no reward);
- Reference consumption and Consumption during the reduction (kWh), when Hilo gives them.
The challenge times are Québec's (America/Toronto), whatever the time zone of your Gladys.
Scenes
Triggers:
| Trigger | Filters | Variables |
|---|---|---|
| Hilo challenge announced | period (morning, evening) | number, rate, pre-heat start, reduction start and end (UTC and Québec time) |
| Hilo challenge phase started | phase (anticipation, pre-heat, reduction, recovery), period | number, phase name, end of the phase (UTC and Québec time), reduction start and end |
| Hilo challenge ended | period | number, result, reward, consumption, reference, energy saved (kWh) |
| Hilo sign-in needed | — | account e-mail, reason |
Examples:
- Phase started: reduction → lower the setpoint of the non-Hilo heaters, turn off the water heater or the EV charger, send a message;
- Phase started: anticipation (with 12 h configured) → start the dishwasher before the peak;
- Challenge ended → send the reward in a message.
Each event is sent once, even when Gladys or the integration restarts in the middle of a challenge. A phase missed while stopped is sent at the restart if it is still in progress.
With the Hydro-Québec integration
The Hydro-Québec integration reads your Hydro-Québec customer account: the official 30-minute consumption (one day late), the Rate D and Flex D contracts with their costs, and the peaks Hydro-Québec announces. Hilo reads your Hilo home: the devices live, their power, and the challenges as Hilo manages them. They complement each other:
| Need | Integration |
|---|---|
| Billed consumption, cost, Rate D / Flex D contract | Hydro-Québec (main meter of Gladys) |
| Live power of the house, per device | Hilo |
| Control thermostats, plugs, water heaters | Hilo |
| Hydro-Québec critical peaks (for every customer) | Hydro-Québec |
| Phases and rewards of the Hilo challenges, anticipation | Hilo |
For the energy dashboard: keep the Hydro-Québec consumption as the main meter (it is the billed one), and attach the energy indexes of the Hilo devices (thermostats, water heater, plugs) to it to see their share. Do not add the energy of the Hilo smart meter on top of Hydro-Québec's: it is the same consumption, counted twice.
Limits
- One location: the first of the account, like the Home Assistant integration.
- Sign-in: Hilo only accepts the redirect address of Home Assistant; hence the copy and paste of step 3. If Hilo changes that rule, a new version will be needed.
- Unofficial API: the one of the Hilo app, as python-hilo documents it. Hilo may change it without notice (it happens every challenge season); the Home Assistant integration follows these changes and this one will too.
- Not yet: the thermostat mode, the bulb colors, the Hilo notifications, the Hilo weather.
Troubleshooting
- "This address carries no sign-in code": copy the whole address of the Home Assistant page, not just its beginning.
- "Hilo refused the code": a code works once and for a few minutes; start again at step 2.
- "Hilo live link lost": the integration reconnects by itself (5 s, then up to 5 minutes between attempts).
- The logs of the integration give the details;
LOG_LEVEL=debugshows more.
Konfigurationseinstellungen
Diese Einstellungen fragt Hilo (Hydro-Québec) in seinem Konfigurationsbildschirm in Gladys ab.
| Einstellung | Typ | Pflichtfeld | Beschreibung |
|---|---|---|---|
| Your Hilo account | section | Nein | Brings your Hilo home into Gladys, live: the challenges (pre-heat, reduction, recovery, rewards) as sensors and scene triggers, the thermostats, switches, plugs, dimmers, water heater controllers and the meter, with their power. 1. Click "Connect" below and sign in to Hilo. 2. Hilo then opens a Home Assistant page (the only address Hilo accepts for this app): copy the whole address of that page from the address bar. 3. Paste it in "Finish the sign-in" under Actions, within 30 minutes. Then add the devices from the Discovery tab. Unofficial, not affiliated with Hilo or Hydro-Québec. |
| Hilo account | account_link | Nein | |
| Challenges | section | Nein | The challenges are the Hydro-Québec peak events Hilo manages for you. Their phases come from Hilo; the anticipation phase is extra: a scene trigger that many hours before the pre-heat, to get ready (0: none). |
| Hydro-Québec rate | select | Nein | Used to follow the challenge details when Hilo does not say it. Automatic reads it from the challenges. |
| Anticipation before the pre-heat (h) | number | Nein | Hours before the pre-heat when the "anticipation" phase starts (0 to 24, 0: none). |
| Lock the setpoints during a reduction | boolean | Nein | Refuses setpoint changes from Gladys while a challenge reduction is in progress, so a scene cannot spoil the challenge. |
| Language of the feature names | select | Nein | Used for the names of the features of the devices added from now on, and for the challenge texts. |
So installierst du Hilo (Hydro-Québec) in Gladys
- Öffne in Gladys Integrationen: Hilo (Hydro-Québec) erscheint im Katalog neben den nativen Integrationen, mit einem Community-Badge.
- Klicke auf Installieren. Gladys lädt das Docker-Image (
ghcr.io/lm1lc3n7/gladys-hilo:0.1.1) herunter, startet es in einer vom Kern isolierten Sandbox und erzeugt die Oberfläche der Integration (Geräte, Erkennung und Konfiguration). - Öffne den Bildschirm Konfiguration der Integration, fülle die Einstellungen aus und speichere.
- Du kannst sie auch direkt über die URL ihres Repositorys installieren: https://github.com/LM1LC3N7/gladys-hilo.
Hilo (Hydro-Québec) benötigt Gladys >=5.1.0. Der Katalog in Gladys wird stündlich aktualisiert, eine neue Version ist also spätestens eine Stunde nach ihrer Veröffentlichung verfügbar.
Du nutzt Gladys noch nicht? Es ist kostenlos und Open Source: folge der Installationsanleitung, um loszulegen.
Über externe Integrationen
Hilo (Hydro-Québec) ist eine externe Integration: eine Community-Integration, die als Docker-Container verpackt und auf GitHub veröffentlicht wird. Gladys installiert sie mit einem Klick und führt sie in einer vom Kern isolierten Sandbox aus. Sie wird von LM1LC3N7 veröffentlicht und gepflegt, nicht vom Gladys-Kernteam.
