Devialet Smart-Home-Integration, kostenlos und Open Source
Devialet Phantom speakers on the local network: volume, mute, source, playback, title.
Veröffentlicht von LM1LC3N7
- Geräte
- Version 0.1.1
- Erfordert Gladys >=5.1.0
- ★ 0
Die Dokumentation dieser Integration wird von ihrem Autor geschrieben und ist bisher nur auf Englisch verfügbar.
Control your Devialet Phantom speakers from Gladys, on your local network, without any cloud: volume, mute, source, play, pause, next, previous, the title playing, and standby. The integration uses the IP control API the speakers expose on your network (plain HTTP), the one the Home Assistant Devialet integration uses.
Unofficial integration, not affiliated with Devialet. This first milestone was written and tested against a simulated speaker only: it has never been tested with a real speaker. Your feedback is welcome.
Prepare the speakers
- Set the speakers up with the Devialet app as usual (Wi-Fi or Ethernet).
- Give each speaker a fixed IP address in your router (reserved DHCP lease). The address is shown in the Devialet app, or in your router's list of devices.
- Gladys must reach the speakers on the network (same network, port 80).
Add a speaker
- By its address (recommended): type the IP address in "IP addresses of the speakers" (several addresses separated by commas) and save. For a stereo pair, one address is enough: both speakers form one system; if both are typed, only one device is shown.
- By the search (optional): use Find the speakers. Gladys browses the
network (mDNS, service
_devialet-http._tcp) for the integration. A speaker in standby, or a network that blocks multicast, may not answer: type the address then. The search is never needed for the rest to work.
The speaker appears in the integration's Discovery tab: create it.
What you get
One Gladys device per Devialet system (one Phantom, or a stereo pair):
| Feature | Detail |
|---|---|
| Power | Read only: 1 the speaker answers, 0 standby, off or unreachable |
| Standby | Button: puts the system in standby |
| Volume | 0 to 100, read and set (whole numbers only) |
| Mute | Button: each press reads the mute from the speaker and sets the opposite |
| Play, Pause | Buttons |
| Next, Prev. | Buttons |
| Playback | Read only: 1 playing, 0 paused |
| Source | Dropdown, read and set: the sources this speaker has shown (AirPlay, …) |
| Now playing | Text: "Artist - Title", or "—" when nothing plays |
Volume and standby act on the system. Playback, mute and source act on the group: when several systems play together (grouped in the Devialet app), a command through any of them applies to the whole group.
The "Source" dropdown lists the sources the speaker announces (Spotify Connect, AirPlay, Bluetooth, UPnP, Roon Ready, optical…). On a stereo pair, the optical input of each speaker is shown with its side ("Optical left", "Optical right"). A source seen once stays in the list; selecting one that is not available at that moment is refused and nothing is sent.
Standby, and turning on
The IP control API cannot wake a speaker up: there is no "power on" command. That is why power is a read-only state and standby a button, not a switch: a "turn everything on" would have nothing to send. A speaker wakes up by itself when something plays to it (AirPlay, Spotify Connect…), or from the Devialet app or its touch surface.
A speaker in standby does not answer the network: it shows as 0 (standby, off or unreachable), the integration status names it, and it is asked again less and less often: after the refresh interval, then twice as long each time, 5 minutes at most. As soon as it answers, it is read at the normal interval again. A speaker that accepts the connection and then says nothing is unknown: nothing is published, Gladys keeps the last known state.
Pressing Standby on a speaker that does not answer does nothing and is not an error (it already is in standby, or off the network).
A speaker that changed address
Each speaker is known by its serial number, not by its address. When another speaker answers at the address of a created one (the router gave it to another device), the integration never sends anything there: the speaker shows 0, the status says "address unknown", and a search runs by itself every 10 minutes until it is found again. You can also use Find the speakers, or type its new address. A fixed address in the router avoids it.
Commands
Every command is answered to Gladys within 5 seconds. Commands to one speaker are sent one at a time; a command that cannot start in time is dropped, never sent late. A volume that is not a whole number from 0 to 100 (empty, 12.5, text…) is refused before anything is sent. When a command may have reached the speaker but was not confirmed in time, Gladys shows "sent, without confirmation" and the state is read again two seconds later; "nothing sent" is only said when no command request left.
Settings
- Refresh interval: how often volume, mute, source and title are read, 5 to 300 seconds (10 by default).
- Check the speakers: asks every known speaker now and says which ones answer, with their volume.
Privacy and security
The integration only talks to the speakers, on your local network, in plain
HTTP (the speakers offer nothing else). It keeps a list of the known speakers
(serial number, address, name, sources) in its data folder (/data). There is
no account and no password. The answers of the speakers are read with a size
limit (64 KB), and only the expected fields are kept.
Limits
- Local network only; the API is the one of the Devialet firmware, which may change.
- No "power on" (see above), no equalizer or night mode, no notification playback in this first version.
- Never tested with a real speaker so far.
Credits
Logic ported to JavaScript from devialet by fwestenberg (MIT license), the library behind the Home Assistant Devialet integration. Devialet and Phantom are trademarks of Devialet, used only to name the compatible products.
Konfigurationseinstellungen
Diese Einstellungen fragt Devialet in seinem Konfigurationsbildschirm in Gladys ab.
| Einstellung | Typ | Pflichtfeld | Beschreibung |
|---|---|---|---|
| Your Devialet speakers, on your local network | section | Nein | Volume, mute, source, play, pause, next, previous, title and standby of each Devialet system (one Phantom, or a stereo pair), through the IP control API of the speakers (plain HTTP on your network), without any cloud. Give each speaker a fixed IP address in your router and type it below; "Find the speakers" can also look for them (optional). The speakers then appear in the Discovery tab. A speaker in standby does not answer: it shows as off, and is asked again at spaced intervals. The API cannot wake a speaker up. Never tested with a real speaker. Unofficial integration, not affiliated with Devialet. |
| IP addresses of the speakers | string | Nein | Separated by commas, for example 192.168.1.30, 192.168.1.31. For a stereo pair, one address is enough. Speakers found by the search are kept without being typed here. |
| Refresh interval (s) | number | Nein | How often volume, mute, source and title are read, in seconds. A speaker that does not answer is asked less and less often (5 minutes at most). |
So installierst du Devialet in Gladys
- Öffne in Gladys Integrationen: Devialet erscheint im Katalog neben den nativen Integrationen, mit einem Community-Badge.
- Klicke auf Installieren. Gladys lädt das Docker-Image (
ghcr.io/lm1lc3n7/gladys-devialet:0.1.1) herunter, startet es in einer vom Kern isolierten Sandbox und erzeugt die Oberfläche der Integration (Geräte, Erkennung und Konfiguration). - Öffne den Bildschirm Konfiguration der Integration, fülle die Einstellungen aus und speichere.
- Du kannst sie auch direkt über die URL ihres Repositorys installieren: https://github.com/LM1LC3N7/gladys-devialet.
Devialet benötigt Gladys >=5.1.0. Der Katalog in Gladys wird stündlich aktualisiert, eine neue Version ist also spätestens eine Stunde nach ihrer Veröffentlichung verfügbar.
Du nutzt Gladys noch nicht? Es ist kostenlos und Open Source: folge der Installationsanleitung, um loszulegen.
