APsystems EZ1 Smart-Home-Integration, kostenlos und Open Source

APsystems EZ1-Integration für Gladys Assistant

Unofficial connector: APsystems EZ1 micro-inverters, live solar production and power limit.

Auf GitHub ansehenAlle Integrationen
Info

Die Dokumentation dieser Integration wird von ihrem Autor geschrieben und ist bisher nur auf Englisch verfügbar.

Unofficial connector, not affiliated with APsystems. It reads your APsystems EZ1 micro-inverters (balcony solar: EZ1-M, and the other EZ1 models that offer the local API) on your local network, through the local API the inverter opens itself: no cloud, no account, nothing leaves your home. APsystems is a trademark of Altenergy Power System Inc.

What you get​

SurfaceContent
One device per inverterproduction power (W, total and per panel), energy today (kWh), lifetime energy (kWh, a production meter index for the Gladys energy monitoring, with its 30-minute production), power limit (W, settable), on/off, reachable, alarms
Scene triggerssolar production started (the morning), solar production stopped (the evening), solar inverter alarm (off grid, output fault, DC short circuit on a panel)
Scene actionsset the solar power limit of an inverter, read the solar production (power, energy of the day and lifetime, of one inverter or all of them)
Dashboard widgetSolar production: power now, energy of the day and lifetime, per panel, the limit and the state of one inverter, or the totals of all of them

Setup​

  1. Enable the local API on each inverter, once: in the AP EasyPower app, connect to the inverter (Bluetooth, "Direct connection"), open Settings → Local mode, enable it and choose Continuous. The app shows the inverter's IP address.
  2. In your router, give each inverter a fixed address (DHCP reservation): the integration finds the inverters by address.
  3. In Gladys, type the addresses in Inverter addresses, separated by commas: 192.168.1.50, 192.168.1.51. The port is 8050; add :port only if yours differs.
  4. Save, then click Test the inverters: each address answers with its model, serial number, firmware and current power. Do it by day: an EZ1 sleeps at night.
  5. Open Discovery and add the inverters. Put the Solar production widget on a dashboard: pick an inverter, or leave it empty for the totals of all of them.

Each inverter is read every 30 seconds (option Refresh interval, 10 s minimum: the EZ1 answers slowly); its alarms and on/off every 5 minutes, its information and power limit every hour.

The night​

An EZ1 is powered by its panels: without sun it switches off, Wi-Fi included. That is normal and not an error: after three readings without an answer, the inverter is shown sleeping (night), its power reads 0 W, its energy counters keep their value, and it is only tried every 5 minutes until it wakes up. The connection status stays green.

The status turns red only when an inverter disappears while producing (at least 50 W at its last answer), or stays silent for a whole day: then check its Wi-Fi, its address, and that local mode is still on.

Energy today is the inverter's own counter since it woke up this morning; it keeps the evening's value through the night and restarts at sunrise. A restart of the inverter during the day (a very dark cloud) is added up, not lost.

Energy monitoring​

The lifetime energy feature is a production index: Gladys turns it into a 30-minute production (the "Lifetime energy (30-minute production)" feature, which Gladys fills itself) for its energy screens. The index never jumps down then up: a single low reading (a glitch at wake-up) is ignored, so it is never counted twice as production.

Power limit and on/off​

  • Power limit: caps the output, within the bounds the inverter reports (30 to 800 W on an EZ1-M). The integration never writes it on its own, and does not rewrite a value the inverter already has. Whether the inverter keeps it in its memory is not documented by APsystems: a scene that changes it every few seconds is not a good idea, once every few minutes is plenty.
  • On/off: stops or restarts the production; the local API keeps answering while the inverter is off. Some firmware (the ones ending in _b, for battery systems) have no on/off: the feature is then not offered.

Scenes​

  • Solar production started: an inverter produced 10 W or more for a minute. Variables: the power and the energy of the day so far.
  • Solar production stopped: under 5 W for 15 minutes, or asleep. Variable: {{triggerEvent.data.energy_today}}, the energy of the day (a good moment for a "today's production" message).
  • Solar inverter alarm: an alarm went up: off grid (check the AC connection), output fault (the AC connection too), DC short circuit (check the panel connector of that input, {{triggerEvent.data.input}}). The first reading after start-up or after the night does not fire: the inverter checks the grid each morning.

In each trigger, pick an inverter or leave it empty for any of them. The variables always hold the inverter's name, {{triggerEvent.data.name}}, and its serial number, {{triggerEvent.data.serial}}.

  • The action set the solar power limit takes an inverter and a value in W, and gives limit, the limit applied.
  • The action read the solar production takes an inverter, or none for all of them, and gives power (W), energy_today and energy_total (kWh), producing, sleeping and inverters (how many were counted), for a message or a condition. It uses the last readings; only an inverter not read yet since the start is read first.

The following actions of the scene find these outputs in their variable list (written {{<step>.<action>.<key>}}, for instance {{0.0.power}} when the read action is the first of the scene).

Troubleshooting​

  • No answer by day: check the address (a fixed one), that local mode is on and set to "Continuous", and that Gladys can reach the inverter's network (the integration runs in a container on the Gladys host).
  • "…does not answer: it sleeps without sun" on a command: the inverter is asleep; try again once it produces.
  • No on/off feature: the firmware has none (see above).
  • The lifetime energy went down: some firmware reset this counter; a single low reading is ignored, a lasting one is published.
  • Logs: the integration's log level is set with the LOG_LEVEL variable.

Privacy​

Everything stays on your local network: the integration only talks to the addresses you typed, over HTTP on port 8050.

Konfigurationseinstellungen​

Diese Einstellungen fragt APsystems EZ1 in seinem Konfigurationsbildschirm in Gladys ab.

EinstellungTypPflichtfeldBeschreibung
Your EZ1 micro-inverters in GladyssectionNeinUnofficial connector, not affiliated with APsystems. It reads your EZ1 micro-inverters (balcony solar) on your local network, through the local API each inverter opens once "Local mode" is enabled in the AP EasyPower app (choose "Continuous"): no cloud, no account. One device per inverter: production power (total and per panel), energy of the day, lifetime energy for the Gladys energy monitoring, power limit, on/off and alarms. Scene triggers when production starts or stops and on an alarm, scene actions to set the power limit and read the production, a dashboard widget. At night an EZ1 sleeps (no sun, no Wi-Fi): that is normal, not an error.
Inverter addressesstringNeinThe IP address of each EZ1, separated by commas (port 8050 by default, add :port otherwise). Give each inverter a fixed address in your router (DHCP reservation). Then open Discovery.
Refresh interval (s)numberNeinHow often the production is read. The EZ1 is slow to answer: 30 s is a good pace, 10 s the minimum. At night a sleeping inverter is tried every 5 minutes only.

So installierst du APsystems EZ1 in Gladys​

  1. Öffne in Gladys Integrationen: APsystems EZ1 erscheint im Katalog neben den nativen Integrationen, mit einem Community-Badge.
  2. Klicke auf Installieren. Gladys lädt das Docker-Image (ghcr.io/lm1lc3n7/gladys-apsystems:0.1.1) herunter, startet es in einer vom Kern isolierten Sandbox und erzeugt die Oberfläche der Integration (Geräte, Erkennung und Konfiguration).
  3. Öffne den Bildschirm Konfiguration der Integration, fülle die Einstellungen aus und speichere.
  4. Du kannst sie auch direkt über die URL ihres Repositorys installieren: https://github.com/LM1LC3N7/gladys-apsystems.

APsystems EZ1 benötigt Gladys >=5.1.0. Der Katalog in Gladys wird stündlich aktualisiert, eine neue Version ist also spätestens eine Stunde nach ihrer Veröffentlichung verfügbar.

Du nutzt Gladys noch nicht? Es ist kostenlos und Open Source: folge der Installationsanleitung, um loszulegen.

Über externe Integrationen​

APsystems EZ1 ist eine externe Integration: eine Community-Integration, die als Docker-Container verpackt und auf GitHub veröffentlicht wird. Gladys installiert sie mit einem Klick und führt sie in einer vom Kern isolierten Sandbox aus. Sie wird von LM1LC3N7 veröffentlicht und gepflegt, nicht vom Gladys-Kernteam.
